Principle: Single beam NDUV254 nm
Units: ppmw, g O3/m3, mg O3/m3
Concentration range: 10, 20, 50, 100 g O3/m³.
Water connection: PFA 1/2″.
Water flow rate: 20 – 600 l/h
Ambient temperature: 2 – 45°C
Reaction time: 5 s (0 – 95%)
Ext. coefficient: 3024 dm3/cm mol (according to DIN 19627)
Analog signal output: 0 / 4 – 20 mA, galvanically isolated
Alarm signal: adjustable 4 x potential free change-over contact
Power supply: 230/110 VAC – 50/60 Hz
Dimensions: H400xW200xD123 mm, optional 19″ rack housing
Optional:
Relay: min./max. limit value, zero point, error message
Digital signal output: RS 232 interface
Digital signal output: Modbus/TCP
External display: 4″ color LCD graphic display with touch function
PC software: ANSEROS AMACS 4.0 (measurement data recording and zero calibration)
