Ozone capacity: 1 … 20 g O3/h
Ozone enthalpy: 14 g O3/h @ 100 Nl/h (SEPgas)
Ozone concentration: 0.1 … 190 g O3/Nm3
Gas flow: 0.1 – 500 Nl/h with needle valve (option)
Frequency control range: 0.1 – 100% capacity
Remote control: interface built in, safety cutoff switch
Carrier gas: any oxygen-containing gas, oil-free
Chiller: ambient air cooling
Dimension: 19”/6HU/450 mm, rack mounting or portable housing
Connector inlet/outlet: ¼” – 6/4 PFA tube
Weight: 18 kg without housing
Power supply: 230/110 VAC-50/60Hz
